Z-axis is equipped with box guideway reinforced through induction hardening process, precision ground and FEM analysis to offer superb cutting rigidity and short force flow
Spindle Speed (Opt.)
10,000 rpm
Spindle Power (Opt.)
45 kW
Spindle Taper (Opt.)
BBT50
X-axis Travel
2,000 mm
Y-axis Travel
1,200 mm
Z-axis Travel (Opt.)
762 mm
Distance Between Spindle Nose & Table Top
200~962 mm
Distance Between Columns
1,340 mm
Table Size
2,000 x 1,100 mm
No. T-slot x Size x Pitch
7 x 22 x 150 mm
Max. Load on Table
4,000 kg
X/Y/Z Rapid Feedrate
20/20/15 m/min
Cutting Feedrate
1~10,000 mm/min
Tool Magazine Capacity (Opt.)
32 (40/60) T
Tool Weight
20 kg/pc
Max. Tool Dimension (W/O Adjacent Tools)
ø125 x 350 (ø240 x 350 ) mm
Machine Weight
19,000 kg
