The Optimal Design and High Rigidity Feed System The million-pulse/rev high-resolution encoders in all axes enable the utmost precision status. The enlarged roller bearing linear motion guides perform extreme rigidity. High load high precision ballscrews ensure high speed high precision axial movements. Fixed volume lubricant distribution system assures comprehensive lubrication. Environmental friendly lubrication-coolant separation design. The symmetry design in castings of base, column and headstock etc. ideally diminishes thermal deformation and ensures accuracy.
Spindle Speed (Opt.)
16,000 (20,000 / 30,000) rpm
Spindle Power (Opt.)
37 (22/11) kW
Spindle Taper (Opt.)
BBT40 (BBT40/BBT30)
X-axis Travel
660 mm
Y-axis Travel
510 mm
Z-axis Travel (Opt.)
400 mm
Distance Between Spindle Nose & Table Top
150~550 mm
Distance Between Columns
960 mm
Table Size
800 x 510 mm
No. T-slot x Size x Pitch
5 x 18 x 100 mm
Max. Load on Table
500 mm
X/Y/Z Rapid Feedrate
20/20/20 kg
Cutting Feedrate
1~20,000 m/min
Tool Magazine Capacity (Opt.)
24 (30) mm/min
Tool Weight
6 kg/pc T
Max. Tool Dimension (W/O Adjacent Tools)
24T：ø75 x 250 (ø150 x 250 ) ( 30T：ø75 x 250 ( ø150 x 250 )) mm
Machine Weight
8,000 kg
