FEM analysis strengthens the structure of the machine to provide the best cutting rigidity with a Box-shape and double column structure design reduce thermal deformation.
Spindle Speed (Opt.)
24,000 (40,000) rpm
Spindle Power (Opt.)
22.5(7.5) kW
Spindle Taper (Opt.)
HSK-A63(HSK-E40)
X-axis Travel
660 mm
Y-axis Travel
510 mm
Z-axis Travel (Opt.)
400 mm
Distance Between Spindle Nose & Table Top
150~550 mm
Distance Between Columns
960 mm
Table Size
800 x 510 mm
No. T-slot x Size x Pitch
5 x 18 x 100 mm
Max. Load on Table
500 kg
X/Y/Z Rapid Feedrate
20/20/20 m/min
Cutting Feedrate
1~20,000 mm/min
Tool Magazine Capacity (Opt.)
24 (24) T
Tool Weight
6 kg/pc
Max. Tool Dimension (W/O Adjacent Tools)
24T：ø76 x 250 (ø125 x 250 ) ( 24T：ø76 x 150 (ø125 x 150 ) ) mm
Machine Weight
8,000 kg
